Product Details:
Payment & Shipping Terms:
|
Temperature Range: | -30~+60℃,-30℃ To 60℃ | Agent: | HFC-227ea |
---|---|---|---|
Advantage 1: | Professional Services,High Quality | Type: | 100kg Portable Automatic Fire Extinguisher |
Material: | Automatic Fire Extinguisher For Firefighting Bus | Capacity: | 180L |
Working Pressure: | 12bar Standard Extinguisher | Cylinder Material: | SS304 Or St12 Red Painting |
Packing: | Cartons And Seaworthy,cartons | Product Name: | Hanging Fire Extinguisher |
High Light: | 40L Kitchen Fire Suppression System,Portable FM200 Fire Suppression System,SS304 Automatic Fire Extinguishers |
The nozzle at the end of the pipeline should be fixed by brackets, and the length of the pipeline between brackets and nozzles should not be greater than 500mm. At least one anti-sway bracket shall be installed in the vertical direction and horizontal direction of the main pipeline with a nominal diameter greater than or equal to 50 mm. When passing through the floors of the building, each floor shall be provided with an anti-sway bracket. When the horizontal pipeline changes direction, the sway bracket should be protected. After the installation of fire extinguishing agent transmission pipeline,
Specification | Technical parameter |
Working pressure | 4.2Mpa |
Type | Fm200 direct type |
Max working pressure | 5.2Mpa |
model | QMQ4.2/100N |
Working temperature | 0-50℃ |
Density of unit volume | ≤950kg/m³ |
Max length of detecting tube | 50m |
Quantity of agent | 100kg |
We can supply different kinds of Automatic Fire Extinguisher below:
FM200 Heptafluoropropane(HFC-227ea) Fire Extinguisher: FM200 Automatical Cabinet Fire Extinguisher System;
If you have questions or requirements,donnot hesitate to let us know,we will supply best service to you in the first time,Including best Program and design for you to save your cost and make it most effective.
We hope our Ding Ya Brand Fire Extinguisher System will be your Important choise.
Thank you very much for your best cooperation and support!
The door
Feature:
1.Fire Equipment is our TOP products.We are most Professional Fire Extinguisher Manafuturer,located in Guangzhou,China.
We can supply different kinds of Automatic Fire Extinguisher below:
FM200 Heptafluoropropane(HFC-227ea) Fire Extinguisher: FM200 Automatical Cabinet Fire Extinguisher System;
If you have questions or requirements,donnot hesitate to let us know,we will supply best service to you in the first time,Including best Program and design for you to save your cost and make it most effective.
We hope our Ding Ya Brand Fire Extinguisher System will be your Important choise.
Thank you very much for your best cooperation and support!
products
Application
The pipe network type fm200 fire suppression system is suitable for a lot of places and several kinds of fires. The followings are some examples for customer as reference:
- Telecommunications and data processing
- Switch gear rooms
- Military applications and cell sites
- High-tech medical application
- Computer rooms
- Telecommunication centers
- Records and data archives
- Testing/imaging equipment
- Reference material
- Chemical laboratories
Feature:
1.Fire Equipment Vaporized completely in the atmosphere without residue and pollution.
2.Colorless,Odorless,non-conductive,insulation,lowest toxicity
3.Beautiful apperance,fashion design and reliable performance.
4.Application:Computer room,Switching Room,Precision Instrument Room,Hospital,TV Station,Railway Station,Museum,Institution,Laboratory,Library,Data Room,Power Factory,Archives etc.
Enterprise production base
water pressure strength test and air pressure leak test shall be carried out. The fire extinguishing agent transmission pipeline shall be purged after passing the water pressure strength test or before the air pressure leak test. Compressed air or nitrogen can be used for purging pipeline. During purging, the gas flow rate at the end of the pipeline should not be less than 20m/s, and it should be checked with white cloth until no rust, dust, water stains or other dirt appears.materials.
