Storage Pressure: | 2.5Mpa | Cylinder Capacity: | 120 |
---|---|---|---|
Working Temperature: | 0-51 Degree | Storage Bottle Material: | HP345 Steel Welding Gas Cylinder |
Usage: | Fire Rescue System,Gas Fire Extinguishing,fire Extinguishing System | Executive Standard: | GB16670 - 2006 |
Capacity: | 150 | Color: | Red |
Company Type: | Manufacturer Over 10-years | ||
High Light: | 120L FM200 Fire Fighting System,CNAS FM200 Fire Fighting System |
cabinet FM-200 Suppression Systems fm200 gas colorless non-toxic gas 120L
In order to make the system more save a space, we know that fm200 / HFC - 227 ea of seven fluorin propane equipment cabinet type can work in the absence of any pipeline network, therefore, compared with the gas pipeline network to suppress the cabinet can save installation space, and make the installation work more easy to do.
International gas fire extinguishing system is mostly pipeline system, including fm200, co2 and ig541, etc. But in China, almost 80% of fire project is using a cabinet without tube gas fire fighting equipment, and why there are so many people like to cabinet fm200 / HFC - 227 ea of seven fluorin propane system, it is easy to install and make it simple.
Model | Storage Device Specification | Agent Volume | Outer Size L*W*H(mm) | Storage Pressure | Discharge Time | Start Voltage/Current | Operating Temperature Range |
GQQ40 / 2.5 | 40L | ≤40kg | 420*480*1250 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
GQQ70 / 2.5 | 70L | ≤70kg | 450*500*1450 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
GQQ90 / 2.5 | 90L | ≤90kg | 480*520*1700 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
GQQ100 / 2.5 | 100L | ≤100kg | 480*520*1700 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
GQQ120 / 2.5 | 120L | ≤120kg | 520*580*1700 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
GQQ150/2.5 | 150L | ≤150kg | 520*580*1830 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
GQQ180/2.5 | 180L | ≤180kg | 520*580*1830 | 2.5Mpa | ≤8s | DC24V/1.2V | 0℃~+50℃ |
For example, a generator room need to use the fm200 / HFC - 227 ea of seven fluorin propane as fire prevention solutions; If you use a cabinet type, so we only need to use a few cabinet extinguishing equipment in the room, then they are evenly placed in the room, in the event of fire, fire extinguishing agent will from cabinet nozzle (the nozzle at the top of the rack) in the discharge direct fire, installation is convenient; If you use the pipe type fire extinguishing system, you may need to separate a gas cylinder storage (cylinder), and then put these cylinders in gas storage chamber (cylinder), and then use the pipeline network connect it to the ceiling of the room, and set up dozens of nozzle on the ceiling of the room. Obviously, the cabinet type has its own advantages and the piping system is not.
In China, the cabinet type has been recognized by the market, and the China fire protection association is highly recommended, we also think that it will gradually be recognized in the international market and recommend.
So far, from Bangladesh, South Africa, Nigeria, Brazil, the united Arab emirates, Vietnam, myanmar and other places of some customers also because in the project use the tripod machine cabinet of HFC - 227 ea fire extinguishing system, all equipment after installation give a high evaluation, they think it is an innovation.
About Dingya
GUANDONG Ding Ya Fire Equipment Co., Ltd. (Called “Ding Ya”),is a Professional Fire Extinguisher manufacturer for more than 10 years.The company which is registered and approved by the Chinese Government is situated at No.3 Dongjing Road,Donghuagongye Village,Renhe Town,Baiyun District,Guangzhou,China.We insist on “Excellent Quality,Perfect Service and Practical price”.
All our products are made according to National and International Standard and are regularly inspected by the Quality monitoring and testing centre for Fire extinguishing ,such as Chinese Government CCC Certificate,EU CE Certificate and ISO9001:2015 Quality Management System.
"Work hard with honesty" is our working attitude and basic principles.We summarized our Enterprise Spirit as "Struggle,Innovation,Harmony and Development,Honest,Gratitude,Unity and Love".WE won several National and International awards and recognition.We have agents from all over the world and we welcome new agents and partners to work together with us to contribute in the Fire Extinguisher Industry.
The main characteristics of the cabinet-type heptafluoropropane fire extinguishing device are high fire extinguishing efficiency, fast speed, easy installation of engineering projects, space saving, economical and practical, and no special bottle storage room is required.
The cabinet type heptafluoropropane fire extinguishing device is composed of heptafluoropropane cylinders, container valves, electromagnetic drive devices, connecting pipes, pressure signals, nozzles and other components. The product has passed 3C compulsory certification
I believe many engineers who do fire fighting engineering are familiar with the difference between cabinet-type heptafluoropropane fire extinguishing equipment and pipe network-type heptafluoropropane fire extinguishing equipment. Today, we mainly share the advantages of cabinet-type heptafluoropropane gas fire extinguishing equipment. Now, many projects mostly use cabinet-type heptafluoropropane because of its flexible and convenient installation mode, which does not need to set up a separate gas cylinder room or set up a gas pipeline, and does not occupy too much space.
Now you can see how people like it, not only is that you like it, this is because the worth you like it, we know that no one is willing to spend a day to complete the installation work of complex, but they like to take the time to just a few minutes to install it, and then spend spare time doing things you love. It will get of everybody love and recognition.
Therefore, when people ask us for our first choice is to recommend they use machine cabinet extinguishing system fm200 / HFC - 227 ea of seven fluorin propane, we can provide the following series.
